CapTouch Cabin Control Wiring Diagrams
JP1 System Selection Jumper
Display Jacks (for 8- or 6-pin display and cables)
Optional Inside Air Temperature Sensor Jack
Required Water Inlet Temperature Sensor
Optional Outside Air Temperature Sensor
JP5 Temperature Sensor Selection
Jumper
Ground
Fan
Water Valve
Electric Heat Strip
Fan Run
Capacitor
L2
L2
L2
AC
L2
L1
L1
L1
L1
Optional
DC Blower
GND
For Humidistat
For Changeover Switch
COM
COM
0-10 VDC
SMX DISPLAYS ONLY
Optional Water-Out Temperature Sensor
3 CW Wiring Diagram
