Dometic Harrier Inverter Technical description
13
6.2 Control panel
The control panel is at the air outlet unit of the roof air conditioner (fig. 2,
page 3).
It contains the following control and display elements:
No. Explanation
1 Button P Switches the roof air conditioner on, off or to
stand-by mode
with status indicator:
Off: The roof air conditioning is switched off.
Red light: The roof air conditioner is in stand-by mode.
White light: The roof air conditioning is switched on.
2
Button
Switches the fan level to:
HIGH, MED, LO, AUTO
3 Display
– Fan
– Mode
– Timer
– Oscillation
– Temperature setting
– °C or °F
4 Button + Increases the temperature setting
5
Button
Switches the front oscillation vent On/Off.
6
Button
Switches the rear oscillation vent On/Off.
7 Button – Reduces the temperature setting
8 Infrared receiver for the remote control
9
Button
Switches the light on or off.
10 Button M Switches the mode to:
COOL, HEAT, DEHUMIDIFICATION,
VENTILLATION, AUTO
