SinePower Technical description
9
The inverter has various protective mechanisms.
• Overvoltage shutdown: The inverter shuts itself off when the voltage exceeds
the cut-off value. It restarts when the voltage returns to the restart value.
• Undervoltage shutdown: The inverter shuts itself off when the voltage sinks
below the cut-off value. It restarts when the voltage rises to the restart value.
• Excess temperature shutdown: The inverter switches off when the tempera-
ture inside the device or the temperature on the cooling element exceeds a cut-
off value. It restarts when the voltage rises to the restart value.
• Overloading and short circuit shutdown: The LED on the inverter indicates
an operating fault when an excess load is connected or a short circuit has
occurred.
I
The inverter can be operated in the following net configurations:
• TN network:
The neutral conductor of the inverter is grounded. A downstream safety switch
(RCD) must be installed.
• IT network:
Both phases are insulated. This is suitable for operating one load. If more than
one load will be connected a protection plan has to be set up (e. g. insulation
monitor).
The net configuration is set via a DIP switch at the inverter.
The inverter can be switched with the remote control to an energy-saving mode to
prevent the connected battery from discharging too quickly.
Using the remote control, the inverter can be turned on or off and switched to the
energy-saving mode.
6.1 Control elements
NOTE
The individual values are found in the chapter “Technical data” on
page 18.
No. in
fig. 2
Description Description
1 Main switch Switches the device on or off
2 Status LED See chapter “Status indications” on page 14
3 Dip switch Sets the net configuration
DSP600-2000--IO-16s.book Seite 9 Montag, 7. Mai 2018 1:39 13
