Dometic DSP612 User Manual

EN
Fitting the inverter SinePower
10
6.2 Connections
I
6.3 Remote control
7 Fitting the inverter
7.1 Tools required
For the electrical connection you will need the following tools:
•Crimping tool
• 3multi-coloured, flexible connection cables. Determine the necessary thickness
from the table in chapter “Connecting the inverter” on page 12.
• Cable lugs and conductor sleeves
For fastening you will require the following tools:
• Machine bolts (M4) with washers and self-locking nuts or
• self-tapping screws or wood screws
NOTE
The version for continental Europe is depicted.
No. in
fig. 2
Description
4 AC outlet
5 Remote control connection
6 DC connection
7 Ground terminal (Earthing on the vehicle bodywork)
8Fan
No. in
fig. 3
Description
1 On/off button
2 Status LED
3 Terminal for remote control
DSP600-2000--IO-16s.book Seite 10 Montag, 7. Mai 2018 1:39 13
