SinePower Connecting the inverter
13
8.2 Connecting the inverter
A
I
➤ Connect the inverter as shown:
– Connecting the battery: fig. 7
– Connecting the ground terminal fig. 8
– Connecting the 230 V output cable: fig. 9
8.3 Connecting the remote control
A
➤ Connect the remote control as shown(fig. 0).
8.4 Connecting external switch (accessories)
I
➤ Close an external switch as shown (fig. a).
NOTICE!
• Make sure that you do not reverse the polarity. Incorrect polarity can
damage the inverter.
• Make sure that the inverter is operated with the following voltage
only:
– DSP612, DSP1012, DSP1512, DSP2012: 12 Vg
– DSP624, DSP1024, DSP1524, DSP2024: 24 Vg
NOTE
Tighten the nuts and bolts to a maximum torque of 15 Nm. Loose
connections may cause overheating.
NOTICE!
Only plug in the connection to the remote control in the remote port.
The device can be damaged by connecting it incorrectly.
NOTE
When using an external switch, you cannot change the status of energy
saving mode.
DSP600-2000--IO-16s.book Seite 13 Montag, 7. Mai 2018 1:39 13
