1. Select panel location away from direct contact with water
and oil.
2. Conrm clearance for wire connections behind wall, hull liner
or bulkhead.
3. Using control panel template (g. 8 , page 5), cut out
panel access hole (E, F) and drill fastener holes (G).
4. With electrical power off, route 18-gauge stranded copper
wire from power source, through circuit breaker or fuse (not
provided), to panel location. Route additional wire according
to diagram (g. 4 , page 3 – see wiring diagram key
below), depending on your application, to panel location.
Make sure wires extend out through access hole.
5. Make proper wiring connections to wires extending from
bottom of circuit panel (g. 3 A 2, page 3).
6. Remove panel cover (g. 3 A 1, page 3) from circuit panel/
mounting frame (A 2), if necessary, by carefully pulling them
apart.
7. Install mounting frame to wall with four fasteners (g. 3 A 3).
8. Push panel cover onto mounting frame until it locks into
place.
1. At step 4 (above), route and connect 14-gauge stranded copper wires according to wiring diagram
(g. 4 , page 3) and wiring diagram key (see below).
2. Insert “Full Tank” shut-down relay into receptacle on back of circuit panel.
6.1 Tank Monitor Panel (g. 3 A, page 2)
6.2 “Full Tank” Shut-down Relay (optional accessory) (g. 1 4, page 2)
DTM04 Panel Template
Dimensions (g. x , page 5)
3
1
Dometic Tank Monitor System Specifications
Caution!
Do not install DTM04 panel in an atmosphere with potentially flammable or
explosive vapors.
Ref. Dimension
A 83 mm / 3.25 in.
B 83 mm / 3.25 in.
C 67 mm / 2.63 in,
D 67 mm / 2.63 in.
E 55 mm / 2.16 in.
F 68 mm / 2.69 in.
G 2 mm / 0.10 in. dia.
H Cut-out area.
Allow 51 mm / 2 in.
clearance behind wall.
6
6
4
4
4
3
3
3
5.3 Dimensions (g. 2 , page 2)
5.4 Approvals
ISO 8846; EMC Directive 2004/108/EC
Ref. Dimension
A 83 mm / 3.25 in.
B 83 mm / 3.25 in.
C 51 mm / 2 in. clearance behind wall
D 10 mm / 0.38 in.
2
Ref. Dimension
E 111 mm / 4.375 in.
F 25 mm / 1.0 in.
G 527 mm / 20.75 in.
H 69 mm / 2.75 in.
6 Installation
To Next Page
