Dometic Elite Control Series User Manual

19
EN
Elite Control Operation
Parameter Name DX CW Factory Default Parameter Range
P-18
Air Filter Cleaning/
Replacement Timer
Setting
x x 0
10–250
Displays the elapsed time (in hours x10) since the timer
was started or reset.
Establish a reminder to clean or replace the air filter. FIL flashes briefly on the LED display every
10 seconds until it is cleared. The FIL reminder can only be cleared and the timer reset via the
programmable parameter P-19.
• The parameter entered represents that number times 10 hours. Select the number of operating
hours until the filter reminder appears.
• Parameter choices are between 10 (100 hours) and 250 (2500 hours).
• Press the Down button to reset the value to 0, restart the timer, and clear the reminder.
I
This setting is applicable to soware revision #A15 and newer.
I
Dometic recommends checking the air filter at least every 500 hours of operation.
P-19
Filter Cleaning/
Replacement Timer
Value & Reset
x x 0
Displays the elapsed time
(in hours x10) since the timer was started or reset.
Display the current elapsed time (in hours x 10) since the timer was started or reset. When this parameter
value reaches the value set in parameter P-18, FIL flashes on the display every 10 seconds until cleared.
Press the Down button to reset the value to 0, restart the timer, and clear the reminder.
I
This setting is applicable to soware revision #A15 and newer.
P-20 CAN Bus Unit ID
x x
dIS Unit ID = 59
(aer enabling and
power cycling)
0–255
Enables all units with a CAN Bus adapter installed to be networked together and communicate with
each other or the ship’s CAN Bus system (with additional translator equipment in some cases).
• The Elite must be plugged into networked Passport I/O and U-boards (this parameter does not
display if the Elite is plugged into a standard board). Each control on the same CAN bus network
must be assigned a unique Unit ID (0 - 255).
• Enter the unit’s CAN Bus Unit ID number.
I
This setting is applicable to soware revision #A16 and newer.
P-21 CAN Bus Group ID
x x
58 (aer enabling
and power cycling)
0–255
Enables all units with a CAN Bus adapter installed to be grouped together in a network system and
communicate with the ship’s CAN Bus system (with additional translator equipment in some cases).
• The Elite must be plugged into networked Passport I/O and U-boards (this parameter does not
display if the Elite is plugged into a standard board). Each control on the same CAN bus network
must be assigned a unique Unit ID (0 - 255)
• Enter the unit’s CAN Bus Group ID number.
I
This setting is applicable to soware revision #A16 and newer.
P-22 Voltage Calibration
x x AC Voltage Adjust to match the accurate voltage reading.
Displays a live reading of the voltage being read by the circuit board. Use the Up and Down buttons
to calibrate for a more accurate voltage level when calculating low voltage for parameter P-6. Use a
reliable voltmeter during adjustment.
I
This setting is applicable to soware revision #A15 and newer.
