Dometic FL 1600 - Technical Data

EN
FreshLight Technical data
37
15 Technical data
Dometic FreshLight
1600 2200
Ref. no.: 9102900207 9102900165
Cooling capacity based on ISO 5151: 1500 W 2050 W
Heating capacity: max. 2050 W max. 2700 W
Rated input voltage: 230 Vw/50 Hz
Power consumption in cooling mode:
Required fuse:
2.7 A
3A
4.1 A
5A
Power consumption in heating mode:
Required fuse:
3.5 A
4A
5.2 A
6A
Operating temperature range: 0 °C to +52 °C
Refrigerant: R407c
Refrigerant quantity: 0.41 kg 0.56 kg
CO
2
equivalent: 0.7273 t 1.1799 t
Global warming potential (GWP): 1774
Blower: 4 blower levels
1 automatic mode
Protection class: IP X4
Max. volume of space in the vehicle
(with insulated walls):
20 m³ 25 m³
Dimensions L x W x H (mm): 1105 x 758 x 210
(height above vehicle roof)
1105
196 684
174 931
210
53
25 – 60
880
758
550
