FreshLight Installation
13
8.4 Laying the connecting cables
D
The roof air conditioner must be connected to an electric circuit which is able to
supply the required current (see chapter “Technical data” on page 20).
➤ Select the cross-section of the cable corresponding to the length:
– Length < 7.5m: 1.5mm²
–Length > 7.5m: 2.5mm²
See fig. 9
➤ Make an opening on one side in order to feed through the electrical power
supply cable.
➤ Feed the 230 Vwcable through the opening into the vehicle interior.
If the lighting should be switched on without the use of a 230 Vwvoltage supply:
➤ Connect the cable with the positive terminal and the negative terminal of the
vehicle battery.
➤ Feed the 12 Vg cable through the opening into the vehicle interior.
8.5 Installing the roof air conditioner
A
See fig. 0
➤ Lift the roof air conditioner onto the roof of the vehicle.
➤ Position the roof air conditioner over the installation opening.
Observe the direction of travel.
DANGER! Danger of electrocution
Make sure there is no voltage at electrically operated components
before carrying out work on them!
NOTICE! Risk of damage
Observe the structural strength of the roof of the vehicle. The roof of the
vehicle must be able to bear the weight of the roof air conditioner. The
roof must not be indented or deformed by the weight of the unit, even
over a longer period of time.
FreshLight-I-16s.book Seite 13 Mittwoch, 8. März 2017 8:55 20
