Dometic Go Power! GP-SB-PWM-30BT User Manual

[page 6] | gopowersolar.com
PRODUCT OVERVIEW
1.3 COMPLIANCE INFORMATION
COMPLIANCE CATEGORY COMPLIANCE LOGO COMPLIANCE REQUIREMENT
RoHS
EU RoHS Directive 2011/65/EU
CE
EU safety, health and environmental
requirements
UL 1471
UL 1741 Standard for Inverters, Converters, Controllers and
Interconnection System Equipment for Use with Distributed
Energy Resources
CU 72181157 Photovoltaic charge controller
Certied to UL1741, C22.2 No. 107.1-16
TUV
1.4 SPECIFICATIONS
DESCRIPTION GP-SB-PWM-10 GP-SB-PWM-30-BT
Nominal System Voltage 12V 12V Dimensions (H x W x D):
125.2 x 73.5 x 27 mm | 4.93 x 2.89 x 1.09 in
Weight: 260 g / 9.2 oz
Maximum Wire Gauge: #8 AWG / 10mm
2
Warranty: 5 years
Features:
• PWM Charging
• 4 Battery Charging Standard Proles
and 1 Custom Prole
• 4-Stage Charging
• Monthly Equalize Option
• Custom Prole
• Lithium Wake-up
• Displays Charging Current, Battery
Voltage, Battery State of Charge, and
Amp Hours Charged Since Last Reset
Nominal Charge Current 10A 30A
Range of Battery Input Voltage 6 – 16 V
Max Battery Charge Current 12.5A 37.5A
Max Solar Power 200W 600W
Input Voltage 35VDC
Max Solar Voltage 28Voc
Operating Consumption
(Display backlight on)
≤15 mA
Battery Types Supported AGM, Sealed, Flooded, LFP (LiFePO4), Custom
Temperature Compensation - 25mV/ºC
Operating Temperature - 40 to 60°C / - 40 to 140°F
Storage Temperature - 40 to + 75°C / -40 to 167°F
Humidity 99% N.C
Ingress Protection IP32
Bluetooth
®
Connectivity NO YES
Protection
• Reverse Polarity on Battery and Solar terminals
• Short-Circuit on Battery and Solar terminals
• Reverse Current from Battery to Solar Terminals
• Over Voltage on Battery and Solar terminals up to 50V
• Over Current, Over Temperature
*Max Charge Current
