Heki3 Plus Scope of delivery
5
3Scope of delivery
4Optional extras
5 Intended use
The Heki3 Plus roof light (ref. no. 9104100292) is suitable for installing in motor-
homes or caravans.
The two lamps cannot be dimmed.
The maximum permissible speed is 100 km/h, as noise or damage could occur
depending on the vehicle design or installation position. The spoilers available as an
optional extra enable a speed of 130 km/h.
No. in
fig. 1
Quantity Designation
1 1 Outer frame with glass dome
2 1 Inner frame
316
16
Fastening screw ∅ 4.0 x 25 mm
Fastening screw ∅ 2.5 x 12 mm
4 16 Mounting bracket
(for roof thickness 25 – 32 mm)
5 10 Ventilation grille
64Lamp covers
7 1 Drive sproket adapter
Designation Ref. no.
Spoiler, 800 mm 9104100236
Spoiler, 1100 mm 9104100237
SunShade roof hood cover 9103500010
