EN
Installing the hoses and grilles (AP and TWIN series only)
Before installing the air components note the following:
• Connect the fan coil to air ducts or pre-insulated pipes.
• The diameter of the main duct must not be smaller than the diameter of the plastic adapter mounted on the fan
(see Hose dimensions on page34).
• Maintain the original diameter of the preinsulated pipes.
• To allow an optimal airflow ensure that the pre-insulated pipes are spread apart and not compressed.
• The flexible supply hose must have a lengh of 2.5… 5 m.
• Do not use plastic grilles or other accessories that are smaller than specified (Technical data on page28).
• Ensure that the ceiling or wall construction does not press on or obstruct the air pipes.
21
