PI8022, PI8023, MO9722 Installing the device
15
2. Affix the device to the worktop using the screws:
– PI8022, PI8023: fig. 7
– MO9722: fig. 8
A
B
h
h
4x
4x
PI8022
PI8023
h= t21 mm
d25 mm
h= t16 mm
d21 mm
7
8x
MO9722
8
