Installing safe proSafe
10
7.2 Attaching the safe
➤ Select a suitable installation location.
➤ Select an appropriate method for installation (attachment on the rear or on the
underside).
➤ Mark the drill holes according to the table below:
Drilling on the rear (fig. 2, page 3)
Drilling on the underside (fig. 3, page 3)
➤ Pre-drill the hole in the mounting location (e.g. in the wall or cupboard).
➤ Attach the safe with a suitable fastening material.
➤ Only for safes with an optional interior socket: Plug the connection cable into the
socket.
Model MD283 MD363 MD383 MD408 MD493
H 82.5 mm 95 mm 95 mm 95 mm 94 mm
L1 35 mm 75 mm 85 mm 97.5 mm 140 mm
L2 210 mm 210 mm 210 mm 210 mm 210 mm
Model MD283 MD363 MD383 MD408 MD493
L1 35 mm 75 mm 85 mm 97.5 mm 140 mm
L2 210 mm 210 mm 210 mm 210 mm 210 mm
L3–––378 mm463 mm
L4 – – – 13.5 mm 13.5 mm
P 117.5 mm 205 mm 225 mm 175 mm 185 mm
