F
or best performance also at high ambient temperatures
t
here must be a free air circulation over the cooling unit at
t
he rear of the refrigerator.
T
he refrigerator is designed for a free-standing installation
a
nd the clearance to side walls etc., should be at least
5
cm (2'').
I
f the refrigerator is to be built-in, openings with sufficient
a
rea must be foreseen for the access and exit of air for the
c
ooling unit, as shown in fig. 2. The letters in the figure refer
t
o:
F Access for cooling air
G Exit for air (upwards)
H Exit forwards (alternative)
I
nstallation in a caravan or motorhome
T
he refrigerator must be installed in a recess (fig. 2) with
t
he dimensions given in TECHNICAL DATA.
T
he refrigerating unit is ventilated via two openings in the
w
all of the caravan. The opening must be fitted with suitable
g
rilles, to give a free cross-section of at least 250 cm
2
.
G
rilles specially developed for this application can be obtai-
n
ed from DOMETIC (model A 1620).
F
our fasteners are fitted in the plastic bushings in the side
w
alls of the fridge, fig. 4. They are used for securing the
r
efrigerator in the enclosure.
T
he side walls of the enclosure and/ or any wooden braces
i
nstalled to fix the refrigerator must be dimensioned to seat
t
he screws securely, also considering the forces due to the
m
ovement of the vehicle.
W
ith the refrigerator in place, drive the screws through the
b
ushings in the lining of the refrigerator into the walls of the
e
nclosure. There must not be more than 3mm of clearance
b
etween refrigerator and enclosure on each side. If neces-
s
ary, wooden strips or similar should be fitted.
N
ote: This is the only approved means of securing the
r
efrigerator to the enclosure and to the vehicle. Fasteners
p
enetrating other parts of the insulation (PU) foam of the
r
efrigerator might damage components like electric wiring
e
tc.
F
lue gas must be exhausted through a flue extension, to be
o
rdered separately or purchased through our service organi-
s
ation,
T
he distance between the flue tube and combustible
m
aterial must not be less than 20 mm at any point. The
s
pace around the tube where it passes through the caravan
w
all should be packed with glass wool protected with
s
uitable metal plates. Install the flue extension as shown in
f
ig. 5.
T
he upper DOMETIC grille has an integrated flue
o
utlet, fig. 7. In this case the traditional flue outlet, is not
n
eeded which simplifies the installation.
I
f there is no outer grille at floor level where leaking gas can
e
scape, a 40 mm hole should be made in the floor of the
r
ecess to drain the gas. The hole should be fitted with wire
m
esh and an angled plate to protect it from stones, mud
e
tc.
L
P GAS CONNECTION
T
he refrigerator is designed for operation on liquified petro-
l
eum gas (LPG), the pressure of which must be:
● for Butane type LPG 28 mbar
● for Propane type LPG 37 mbar
C
heck that this is stated on the data plate.
T
he refrigerator is not designed for operation on town gas or
n
atural gas.
T
he gas equipment is shown in fig. 6. In the burner (P) is a
t
hermocouple (O), which generates an electric current
t
hrought the flame failure device (N), keeping it open as
l
ong as the flame burns. The valve (M) opens/closes the
g
as mechanically. It also has a ``MIN'' position for cold
w
eather. The piezo igniter (L) is connected to the spark plug
(
Q). The gas connecting tube (K) has a nipple (J) with left
h
and thread R 1/4.
.
.. in open air applications
F
or this application a hose connection to the LPG-bottle is
u
sed. Only use rubber hose with crimped on connectors
a
pproved for LPG.
A
pressure regulator (as described above) is assembled to
t
he LPG-bottle. Check that the rubber gasket in the shut off
v
alve of the bottle is clean and undamaged, as also the
s
ealing surface in the pressure regulator. The nut should
o
nly be thightened by hand - otherwise the gasket might be
d
amaged.
T
he connection is made as follows (figs. 6/9):
● Put the refrigerator on its side
● Connect hose to nipple (J) and thigten by hand. (Note:
left hand thread!).
● Thigten carefully with a wrench, thereby holding the
nipple (J) with second wrench.
● In the same way, connect other end of hose to pressure
regulator on LPG bottle.
● Open shut off valve of bottle, putting the hose under
pressure.
● Check for leaks at the connections, using water with
detergent, watching for bubbles. If leaking: carefully
thigten with two wrenches as explained above until
formation of bubbles stops.
● In similar way check also thigtness between nipple (J)
and tube (K) and thighten if necessary.
● Also check connection between pressure regulator and
LPG bottle. If leaking, clean sealing surfaces and inspect
for damage. If found defective: exchange (return LPG
bottle), but do not use any foreign sealing compound.
C
AUTION: If there are still leaks, call in a service
technician.
.
.. indoors
T
he gas installation should only be carried out by an
a
uthorisid gas fitter.
CAUTION !
CHECK THAT THE GAS SUPPLIED TO THE
REFRIGERATOR IS AT THE CORRECT PRESSURE.
CHECK THE REDUCING VALVE ON THE LP GAS
11
