Dometic RM 5380 Installation Instructions

8
3.3 Technical data
Description of model
Fig. 3Fig. 2
RM 5310
RM 5330
H
B
T
RM 5380
Fig. 4
RM 5310
RM 5330
RM 5380
618x486x474
821x486x474
821x486x474
60 lit.
70 lit.
80 lit.
20 kg
22 kg
24 kg
125 W / 120 W
125 W / 120 W
125 W / 120 W
•
•
•
ca.2,5 KWh / 270 g
ca.2,5 KWh / 270 g
ca.2,5 KWh / 270 g
Model Dimensions Gross capacity Rating details Consumption * Net Ignition
H x W x D (mm) freezer mains/battery electricity/gas weight Piezo Automat
Depth incl. door compartment over 24hrs
5 lit.
5 lit.
5 lit.
Subject to technical changes.
*Average consumption measured at an average ambient
temperature of 25°C in pursuance of ISO Standard.

Dometic RM 5380 Specifications

General

Door hinge	Left
Product color	Black, Grey
Custom panel-ready	-
Appliance placement	Freestanding
Refrigerating medium	R717
Noise level	- dB
Climate class	SN
Total net capacity	75 L
Total gross capacity	80 L
Lamp type	LED
Fridge net capacity	70 L
Fridge interior light	Yes
Freezer position	Top-placed
Freezer net capacity	5 L
Current	0.54 A
Power source	Gas/Electric
Connected load	125 W
Gas consumption	270 g/24h
AC input voltage	230 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	- kWh
Package depth	543 mm
Package width	523 mm
Package height	845 mm
Package weight	29000 g

Weight and Dimensions

Depth	474 mm
Width	486 mm
Height	821 mm
Weight	24000 g
