Dometic RM1350 Diagnostic Service Manual

4
Symptom Cause Section & Page
1. No operation - no panel lights Operation
DC Volts
Fuse
Wiring
Control Panel
LED Display Board
Lower Circuit Board
1, Page 13
4, Page 18
5, Page 23
5, Page 21 & 6, page 30
5, Page 21
5, Page 21
5, Page 22
2. No operation - has panel lights
Operation
DC Volts
Thermistor
Wiring
Lower Circuit Board
1, Page 13
4, Page 18
5, Page 19
5, Page 21 & 6, page 30
5, Page 22
3. No AC operation - operates on gas mode Operation
AC Volts
Fuse
Heating Element
Wiring
Lower Circuit Board
1, Page 13
2, Page 16
5, Page 23
3, Page 16
5, Page 21 & 6, Page 30
5, Page 22
4. No Gas operation - operates on AC mode Operation
LP Gas
Manual Gas Valve
Igniter
High Voltage Cable
Electrode
Solenoid
Wiring
Lower Circuit Board
1, Page 13
7, Page 30
8, Page 30
5, Page 20
5, Page 20
5, Page 20
5, Page 19
5, Page 21 & 6, Page 30
5, Page 13
5. Insufcient cooling on all modes.
Ventilation
Leveling
Ambient Temperature
Air Leaks
Thermistor
Cooling Unit
9, page 33
9, page 33
9, page 38
9, page 37
5, page 19
9, page 38
6. Insufcient cooling on AC - cools properly on gas mode.
AC Volts
Heating Element
Lower Circuit Board
2, page 16
3, page 16
5, page 22
7. Insufcient cooling on Gas - cools properly on AC mode.
LP Gas
Orice
Flue Bafe
Flue Tube
Burner
Lower Circuit Board
7, page 30
8, page 31
8, page 32
8, page 32
8, page 32
5, page 22
This program will address the most common system problems associated with the RM1350 refrigerator supplied by Do-
metic LLC. Our intent is to provide you with a guideline of checks to make, should you encounter one of the following
symptoms.

Dometic RM1350 Specifications

General

Brand	Dometic
Model	RM1350
Category	Refrigerator
Language	English
