TEC29 EV AUS Technical description
23
Control elements in the digital control panel
The digital control panel is installed in the vehicle interior.
Displays
No. in
fig. 4,
page 4
Description
1 Display Shows the status reports.
2 On/Off switch P Switches the digital control panel on and
off if the main switch is at “I” or “1”.
Stops the generator.
3 START/STOP button Starts and stops the generator if the
digital control panel is switched on and
the main switch is at “I” or “1”.
4 Oil LED Lights up if the oil level is too low in the
engine.
5 Petrol LED Lights up if the petrol goes into reserve.
No. in
fig. 4,
page 4
Description
6 AC supply Approximate voltage (±5 %)
7 Power output Power draw through connected load
8 Operating hours Time the generator is in operation
9 DC voltage Battery voltage
10 Messages Status reports of the generator (see
chapter “Display messages” on page 34)
