TECHNICAL REFERENCE
L025317 Issue 5 July 2014 4-9
D-Series Laser Marking System (60 Watt
Versions)
*Characters per second and production line speeds are substrate and code dependent
**Dimensions measured overall for shortest version
D-Series Models D620i 10mm or 15mm Scan Head
Laser Power
60W
(approx. 60W for Blue tube option @ wavelength of 9.3μm)
Laser Peak Power P
0
120W
Laser Type
Sealed-Off CO
2
Laser
Wavelength 10.6μm typical (9.3μm as Blue tube as option available)
Duty Cyle* 100%
Maximum Laser On
Time
No limit
Code Types Logos, bar codes, 2D codes, graphics, text, etc.
Characters per second* 2000*
Product Line Speed*
600m/min*
1970ft/min*
Character Height
0.6mm - field size
(0.02in - field size)
Focal Length
i-Tech 10: 80, 100, 120, 150, 200, 250mm;
i-Tech 15: 250, 325, 450mm
Marking Field
i-Tech 10: 58 x 58, 68 x 68, 84 x 84, 102 x 102, 136 x 136,
180 x 180mm
i-Tech 15: 200 x 254, 262 x 334, 356 x 452mm
Fonts 24 fonts, multi-language including full Unicode
Scan Head
i-Tech Scan Head, mountable in various orientations including
axial and radial
Laser Head Stainless steel and anodised aluminium construction
Dimensions
(L x W x H)**
846.1 x 140 x 180 [mm]**
(33.4 x 5.5 x 7.1 [in])**
Weight
27.3 kg (60.2 lbs) (air cooled)
30.0 kg (66.2 lbs) (water cooled, without coolant))
Operating Temperatures 5º to 40º C (41º to 104º F)
Environmental Humidity Max. 90% RH, non-condensing
Cooling Air, Water
