Pin Description Pin Description
3 Product Detect 2 (PD2) 4 Output 24 V DC
5 Product Detect 3 (PD3) 6 Product Detect 3/4 Common
7 Product Detect 4 (PD4) 8 Output 24 V DC
9 Product Detect 1/2 Common 10 Ground
11 External Output 1 Common 12 External Input 1 Common
13 External Output 1_1 14 External Input 1_1
15 External Output 1_2 16 External Input 1_2
17 External Output 1_3 18 External Input 1_3
19 External Output 1_4 20 External Input 1_4
21 External Output 1_5 22 External Input 1_5
23 External Output 1_6 24 External Input 1_6
25 External Output 1_7 26 Ground
27 External Output 1_8 28 Ground
Gx-OEM Serial Number E79888D0G111241 or Earlier, and Gx-IC10 E79961F0G111197 or
Earlier.
Pin Description Pin Description
1 Product Detect 1 (PD1) 2 Not Used
3 Product Detect 2 (PD2) 4 Not Used
5 Product Detect 3 (PD3) 6 Not Used
7 Product Detect 4 (PD4) 8 Output 24 V DC
9 Product Detect Common 10 Ground
11 External Output 1 Common 12 External Input 1 Common
13 External Output 1_1 14 External Input 1_1
15 External Output 1_2 16 External Input 1_2
17 External Output 1_3 18 External Input 1_3
19 External Output 1_4 20 External Input 1_4
21 External Output 1_5 22 External Input 1_5
23 External Output 1_6 24 External Input 1_6
25 External Output 1_7 26 Not Used
27 External Output 1_8 28 Not Used
INSTALLATION
45 EPT053091 - Issue 5 - 07 May 2021
