Donaldson Company, Inc.
Inlet
.
Filters
are installed in the correct orientation and direction during servicing.
Delta P-C01 Control
The DFEP ships with a Delta P controller to monitor differential pressure between the clean-air and dirty-air plenums and provides
The Delta P control and a pulse control timer manage pulse cleaning from user established High and Low Pressure Set Points. An
The Delta P controller includes start/stop buttons to control fan motor operation and an E-stop for emergency shut-down of the
DFEP fan and pulse cleaning controls.
For complete information see the current Delta P Installation, Operation, and Maintenance manual.
Standard Equipment
air inlet box
with collar
clean air collector
exhaust
compressed air
connection
control box
with Delta P
C-01 and
motor starter
collector exhaust
electrical service
connection (junction
box)
cover
sprinkler tap
dust bin access
door (open)
dust bin
