Donner DDP-300 - Piano Assembly; Electrical Piano Overall Assembly

NO.
1
2
3
4
5
6
7
①
②
④
③
⑤ ⑥ ⑦
PARTS
Piano Body
Left stand board
Right stand board
Back plate
Pedal box
Screws M6 x 24(12PCS)
Thumb screw M6 x24(4PCS)
Piano Assembly
Electrical Piano Overall Assembly
Before you are ready to assemble the piano, please check if
all parts are included in the package box.
A. Use screws to fix the pedal box onto the left and right stand boards.
(Make sure the direction is correct before installation.)
01
