REMARK！
● Please follow the instructions and read the "safety precautions" in the User Manual carefully
before using it.
● When you have completed the connection, please turn on the power according to the instructions
in the User's Manual and check whether you can hear the sound.
● This product needs adult to install, do not let the minor install it independently.
INSTALLATION GUIDE
3
MY ELECTRONIC DRUM
01
Check the attached items
Sound module Module bracket Hi hat Ride
Tom-tom
(3pcs)
Snare Cymbal mounts
（3pcs）
Drum mount
（4pcs）
KickFixed partsSupporting parts Fastening screw Kick pedalStick hammer
Hi hat pedal
Signal Connection Linedrum stick power adapter Drum keyBolt driver Inner six angle
● After opening the package, please check whether it contains all the items immediately.
If there are any omissions, please contact your dealer.
Crash（2pcs） Crash2 line
2pcs 2pcs 2pcs4pcs
Hi hat mount
