MY ELECTRONIC DRUM
Plug the parallel plug into the
host box according to the figure,
then insert the corresponding
hole position of the hitting part
follow the English label of the
head of the connecting line.
INSTALLATION GUIDE
10
Insert Connection Line
● Please insert the connecting wire in place to avoid bad contact and insert it correctly
follow the diagram.
hi-hat
crash ride
tom1
module box
tom2
snare
Kick drum
hi-hat pedal
tom3
crash
