DONPER XF124 - Page 18

Model 3311
Page 21
XF124
Base Assembly
115V Water-Cooled Model
ITEM PART NUMBER DESCRIPTION
10 W0210068 BASE PAN
20 W0201001 COMPRESSOR ASSEMBLY
30 W0321026 DRIVE MOTOR ASSEMBLY
40
W0210083 FRAME ASSEMBLY
50
W0611410 RIVET, MAGNA LOCK
60 W0611082 5/16-18 FLANGE NUT
70 W0200412 COMPRESSOR SPACER
80 W0200413 COMPRESSOR GROMMET
* See condenser assembly on page 34.
