DONPER XF124 - Part Number Description

Page 20
Model 3311
XF124
Base Assembly
220V Air-Cooled Model
ITEM
PART NUMBER
DESCRIPTION
ITEM
PART NUMBER
DESCRIPTION
10
W0210083
FRAME ASSEMBLY
70
W0611410
RIVET, MAGNA LOCK
20
W0201007
COMPRESSOR ASSEMBLY
80
W0611247
1/4 INT. TOOTH LK. WSHR.
30
W0201002
CONDENSER ASSEMBLY
90
W0611074
1/4-20 HEX NUTS
40
W0321040
FAN SUB-ASSEMBLY
100
W0611082
5/16-18 FLANGE NUT
50
W0321041
DRIVE MOTOR ASSEMBLY
110
W0200412
COMPRESSOR SPACER
60
W0210106
BASE PAN ASSEMBLY
120
W0200413
COMPRESSOR GROMMET
