DoorHan DCUH-1 Owner's Manual

7
Fig. 1. Control unit design
Table 1. Spare parts for the control unit
* Cables are connected to hydraulic stations and supplied with the dock levelers.
Table 2. Connecting cables to the dock leveler control unit*
# Part name Part number
1 DCUH-1 main board PCB_DCUH1-M/V.1.2(3)
2 DCUH-1 control board PCB_DCUH1-BT/V.1.0
3 Switch assembly DCU007
APPENDIX
3
2
1
# Part name Length Part number
- Connecting cable for DCUH-1/2/3 control units 7 m DKHL02-2
- Connecting cable for DCUH-1/2/3 control units 10,5 m DKHL02-3
APPENDIX. RECOMMENDED SPARE PARTS

DoorHan DCUH-1 Specifications

General

Brand	DoorHan
Model	DCUH-1
Category	Control Unit
Language	English
