PROGRAMMING
6.2. ENTERING TO THE PROGRAMMING MODE
To enter the programming mode, switch on the control unit, turning the main switch to position «I». Make sure that the control
unit power indicator lights, press briefly ‘Down’ button, then simultaneously press the “UP” button and “Auto” button within five
seconds. «UH *» symbol in digital display means that you are in the programming mode (* - Flashing). Programming menu DCUH-
2 shown in Table 2.1.»
«If the time to make service is coming, the operation display is blocked. In this case, «Ser» permanently displayed and service
LED lights. Reset flag service main- tenance performed in the extended menu. The same applies to the error indication; if during
operation occurred exceptional situation, the de-energizing the system to the display will show a message «ErX», where X - number
error. Number of the last emergency case can be viewed in the extended menu.»
Programming menu DCUH-3 shown in Table 2.2.
Table 2.1.
PARAMETER RANGE DESCRIPTION
1. «UH»
Parameter value 1-9 (3-11sec.) Default value 7 sec.
Changing by 1 = 1 sec.
Lifting time in parking mode
2. «UC»
Parameter value 1-9 (5-21sec.) Default value 13 sec.
Changing by 1 = 2 sec.
Lowering time in parking mode
3. «Hd»
Parameter value 1-9 (2,5-6,5sec.) Default value 4,5 sec.
Changing by 1 = 0,5 sec.
Lifting time of last part of parking
4. «AF» Parameter value 1-9 "Threshold stop, apply to the action: ""Lifting platform"""
5. «Ar» (Y/n), default value - «Y» Y = Parking mode On. N = parking mode OFF
6. «CXX» (0-99) Cycle counter /1000
7. «SXX» (0-99) Service counter
8. «EXX» (0-99)
"The indicator last emergency situation:
«E00» - emergency for the entire period of operation did not occur;
«E01» - an error of use;
«E03» - a short circuit in the motor winding in powerpack;
«E04» - a short circuit on the control board and display."
9. «rS»(1) (Y/n), default value - «n» Reset of service mode
Table 2.2.
PARAMETER Range Description
1. «UH»
Parameter value 1-9 (3-11sec.) Default value 7 sec.
Changing by 1 = 1 sec.
Lifting time in parking mode
2. «UC»
Parameter value 1-9 (5-21sec.) Default value 13 sec.
Changing by 1 = 2 sec.
Lowering time in parking mode
3. «Hd»
Parameter value 1-9 (2,5-6,5sec.) Default value 4,5 sec.
Changing by 1 = 0,5 sec.
Time of the apparel pulling in
4. «AF» Parameter value 1-9 "Threshold stop, apply to the action: ""Lifting platform"""
5. «dL» (Y/n), default value - «n» Automatic door closing
6. «Ar» (Y/n), default value - «Y» Y = Parking mode On. N = parking mode OFF
7. «CXX» (0-99) Cycle counter /1000
8. «SXX» (0-99) Service counter
9. «EXX» (0-99)
"The indicator last emergency situation:
«E00» - emergency for the entire period of operation did not occur;
«E01» - an error of use;
«E03» - a short circuit in the motor winding in powerpack;
«E04» - a short circuit on the control board and display."
10. «SL» (Y/n), default value - «Y» Y = Inflatable dock shleter = On. N = Inflatable dock shleter = Off
11. «Sb»
Parameter value 1-9 (17-35sec.) Default value 25 sec.
Changing by 1 = 2 sec.
Deflating time
12. «Gd»
Parameter value 1-9 (2-18sec.) Default value 10 sec.
Changing by 1 = 2 sec.
Time of door closing
13. «rS»(1) (Y/n), default value - «n» Reset of service mode
