GENERAL INFORMATION
1. GENERAL INFORMATION
Multi-function code keypad is designed to control automatic enclosing structures using Proximity cards and / or a PIN.
Durable anti-vandal housing and reliable insulation of electronics make it possible to install the device both inside and outside the
premise.
Such additional functions as lockup at short circuit and signalling in case of tampering are available in the device. LDR (light
sensitive resistor) installed in the device prevents it from being tempered. If the keypad housing is removed, an alarm will be triggered.
Parameter Value
Supply voltage 9 – 28 VDC
Active current < 60 mA
Idle current (25 ± 5) mA
Lockup output load 3A max.
Signal output load 20A max.
Operating temperature range -45…+60°C
Protection class IP68
Adjustable time of door relay 0–99 seconds
Adjustable time of signalling 0–3 minutes
Interface Wiegand 26 bit
Maximum number of users 2 000
Card reading distance 3–6 cm
Supported cards 125 KHZ EM
Wire connections Electric locking, exit pushbutton, external signal
Table 1. Technical specifications
1.2. DESCRIPTION OF WORK
Main components of the code keypad are: a push-button control panel (controller), remote (Proximity) cards, various tokens
or fobs each of which contains a unique ID code. If the card (fob etc.) code, PIN meets the predetermined requirements the
automatics opens the electronic lock of the door (barrier, turnstiles, gates). The user database and full logics of system operation
are stored directly in the controller itself.
1.3. INSTALLATION
1. Remove the back cover from the keypad using the enclosed special screwdriver.
2. Drill two holes in a wall for two self-tapping screws and one hole for a cable.
3. Install the enclosed rubber plugs in two holes.
4. Fix the back cover on the wall using two self-tapping screws.
5. Run the cable through the cable holes.
6. Connect the keaboard to the back cover.
1.1. CARTON INVENTORY
After receiving the device, it must be unpacked and inspected for damage. In case of any defects, please contact the supplier
of the device.
Description Quantity Notes
Keypad 1
User manual 1
Screwdriver 1
�20 × 60 mm, special
Rubber plug 2
�6 × 30 mm, for fixation
Self tapping screw 2
�4 × 28 mm, for fixation
Screw with star washer 1
�3 × 6 mm, for fixation
Table 2. Inventory
