8
Brackets mounting angle depends on the gate opening parameters and is adjusted directly at the installation site.
Rear bracket mounting angle
Front bracket mounting angle
98 mm
90 mm
95 mm
78 mm
68 mm
40 mm
28 mm
158 mm
145 mm
55 mm
60 mm
155 mm
120 mm
114 mm
INSTALLATION
