Page 24 1506-065-F-3-14
4.2 Data Tables
Use the tables below to record data entered into the keypad system.
MASTER CODE
4-DIGIT HOLD BOUNDARIES
LOWER
UPPER
4-DIGIT DIVIDE NUMBER
5-DIGIT DIVIDE NUMBER
TIME ZONE 1 BOUNDARIES
LOWER
UPPER
TIME ZONE 2 BOUNDARIES
LOWER
UPPER
5-DIGIT ENTRY CODES
1
2
3
4
5
6
