1506-065-F-3-14 Page 7
1.1 Mounting
Surface mount units can be mounted directly to a wall or pilaster, or they can be mounted using a
gooseneck mounting post (p/n 1200-045 or 1200-046).
SECTION 1 - INSTALLATION
1
#0*
7 8 9
654
32
10.0 5.25
2.875
6.125
3.0
5.0
2.5
2.5
.875
1.25
1.31
.875 Dia
Model 1504 Surface Mount
6.375
4.375
2.5
2.5
.25
.875
5.25
1 2 3
654
987
#0
*
Model 1506 Surface Mount
