DoorKing 1600 Series Manual

2600-267-G-6-16
Green
Model 9150
Installation for a 115 VAC 9150 operator ONLY.
Step 1: Mount step-down transformer on the (4) four existing threaded studs (below the motor) using the (4) four nuts supplied with this kit.
Attach the wires acrossed the top of the main support bracket. Avoid moving parts.
TIP: It is MUCH easier to install the step-down transformer before mounting the operator and attaching the chain. Flip operator upside down for access.
Step 2: Wire the step-down transformer for the desired input voltage chosen (see first page).
Operator MUST be
properly grounded.
Black
White
115 VAC Input
115 VAC Output
115 VAC Output
115 VAC Operator
Power Terminal
Chassis Ground
Hot
Hot Hot
Neu
Neu
Step-Down
Transformer
Power Terminal
REV
ER
SE
SENSIT
I
VIT
Y
REVERS
E
LOO
P
EX
IT
LOOP
KEY SW
ITCH
DOORKING
4602-01
0
SW
1
SW
2
OP
EN
TIMER
Step-Down
Transformer
Mounting
Position
Keep wires away
from moving parts.
DANGER
HIGH VOLTAGE!
Main
Support
Bracket
Dual Gate Operators Installation: When installing on bi-parting gates,
a step-down transformer and AC input power wire is required for
EACH operator.
“Optional” Heater Installation: When installing
a heater, refer to the “high voltage AC
power wire size and distance
limitations” table on the instruction
sheet with the heater kit for AC
input power wire run
limitations.
Important Notes:
Variable Input Power
(see first page)
Double check your chosen input voltage plug BEFORE
applying power to the step-down transformer. Failure to
choose the CORRECT input voltage plug for your desired
input voltage WILL damage operator and VOID warranty.
