MAINTENANCE Operating & Maintenance Manual
Book: 46551819 (2-11-2011) Rev B 45
To ensure freedom from air leaks, all rubber hose joints and the screw-type hose clamps must
be absolutely tight. Regular inspection of these connections for wear or deterioration is
necessary.
Premature wear of both the engine and compressor is ASSURED whenever dust-laden air is
permitted to enter the engine’s combustion chamber or compressor intake.
The flexible hoses used in the fuel, oil and air lines on these units are primarily used for their
ability to accommodate relative movement between components. It is important they be
periodically inspected for wear and deterioration. It is also important the operator does not use
the hoses as convenient hand hold or steps. Such use can cause early cover wear and hose
failure.
NOTICE
Some of the airlines are nylon tubing. The associated fittings are “push-in” design.
Features are as follows:
Pulling on the tubing will cause the inner sleeve to withdraw and compress, thus tightening the
connection. The tubing can be withdrawn only while holding the sleeve against the fitting. The
tubing can be removed and replaced numerous times without losing its sealing ability.
To install the nylon tubing, make a mark (with tape or grease pencil) approximately 7/8 inch
from the end of the tubing. Insert the tubing into the sleeve and “push-in” past the first
resistance to the bottom. The mark should be approximately 1/16 inch from the sleeve, for the
3/8 inch O.D. tubing; 1/8 inch for the 0.25 inch O.D. tubing. This will ensure that tubing is fully
engaged in the sealing mechanism.
Compressor Oil Filters
The oil filter must be replaced every 500 hours of operation or six (6) months, whichever
comes first.
To service oil filters it will first be necessary to shut the unit down. Wipe off any external dirt
and oil from the exterior of the filter to minimize any contamination from entering the lubrication
system. Proceed as follows:
