DL06K Interim Tire-4 Diesel Engine Technical Information
32
2.3.19. Inter cooler
z The air cooling method is used for the inter cooler, and the sufficient cooling
capacity is provided.
The life and performance of the inter cooler heavily depends on the intake air
conditions.
z Dirty air pollutes and blocks inter cooler fins. As a result, it drops the engine
output and cause engine failure.
Therefore, you should always check whether the air filter in the intake system is
damaged or polluted.
FG000492
Air/air intercooler with radiator
(combined radiator)
Air flow by cooling fan
Hot air by turbo charger compressor
Cooled air to intake manifold (max. 50
)
