DL06K Interim Tire-4 Diesel Engine Disassembly and Reassembly of Major Components
78
z Outside diameter of tappet
With an outside micrometer, measure
the tappet outside diameter if the
measured value is beyond the limit,
replace tappets.
(mm)
z Push rod run-out
Use a feeler gauge to measure the
push rod run-out.
Roll the push rod along a smooth flat
surface as shown in the figure.
(mm)
5) Rocker arm assembly
z Reassembling can be done in the reverse order of disassembling and following
things should be heeded.
z Check the oil supply hole of rocker arm shaft for any clog and clean thoroughly.
z Be careful, not to occur any swap of position and reverse assembly.
Standard
24.90 ~ 27.982
Limit 0.25 or less
Push rod length 344
EDM2061I
EA0M4073
Feeler gauge
