Operating Controls
OP001013
2Operating Controls
The "Operating Controls" section presented here consists of the
following groups:
1. “Component Locations” on page 2-2
2. “Operator's Area” on page 2-4
3. “Steering Console and Pedals” on page 2-5
4. “Front Instrument Panel” on page 2-14
5. “Right Side Switch Panel” on page 2-25
6. “Various Cabin Locations” on page 2-40
7. “Heater and Air Conditioner Operation” on page 2-44
8. “Stereo / CD Player (Optional)” on page 2-49
9. “Seat Adjustment” on page 2-51
10. “Seat Belt” on page 2-53
11. “Door Side Latch” on page 2-54
12. “Arm Rest” on page 2-55
13. “Fuse Box/Relay/Engine Emergency Stop Switch” on
page 2-56
Each group is explained with a point location drawing or photo
and a brief description of each control, switch, gauge or valve.
Indicator lights work besides the gauges on the instrument
panel. The operator should monitor machine pressure on the
instrument panel along with indicator lights. These lights will only
show that there is a problem.
WARNING
Warning lights. When any one or more of the warning lights
on the control console come "ON," immediately stop
operation and shut down unit. Investigate and correct
problem before proceeding with operation.
