Technical Information
- 24 -
2.3.12. Engine control module : ECM
 This engine control module is used to
control the engine for a natural as
application. It is used in conjunction
with various actuators, sensors, etc to
make up a system.
CAUTION :
Do not connect or disconnect the
ECM to/from the wiring harness
without first removing the negative
(-) battery cable from the battery.
Denoxtronic Control Unit.
Do not perform remove the inner parts
of the engine control module (ECM).
2.3.13. Ignition control module : ICM
 A synchronization pulse(index) is also
sent by the ECM to the ICM so that the
ICM fires the correct coil.
CAUTION :
Do not perform remove the inner
parts of the ignition control module
(ICM).
(ECM)
J2-B
J2-A
J1-C
J1-B
J1-A
EI4OM009
Engine control module
EJ2OM003
Ignition control module
(ICM)
P62
Ignition coil harness
