Technical Information
- 32 -
2.3.25. Starting motor
 The sliding-gear starter motor is flanged to the rear of the flywheel housing on the left-hand side. As
parts of every engine overhaul, the
 starter pinion and ring gear should be cleaned with a brush dipped in fuel and then a coat of grease
should be applied again.
EJ2OM006
Battery terminal
Terminal switch
24V x 6.0kW
Magnetic
switch
Starting motor
Battery terminal
Battery terminal
Battery switch
EI4OM023
M
M
S
Wiring harness
