Maintenance - 51 -
3.1.19. Water pump
 Unclamp the rubber hose connected to
the oil cooler.
 Unscrew the water pump fixing bolts
from the cylinder block and take off the
water pump.
3.1.20. Starter
 Unscrew the starter fixing nuts and
remove the starter being careful not to
damage its gears.
3.1.21. Ignition control module : ICM
 Loosen the fixing bolt, then
disassemble the ignition control
module(ICM)
3.1.22. Fuel metering valve
 Disconnect metering valve on the fuel
delivery and suction hose.
 Loosen the fixing bolt, then
disassemble the metering valve.
EB5M3011
EJ3OM014
EJ2OM003
Ignition control module
(ICM)
P62
Ignition coil harness
EJ2OM007
