9.3.18. Oil pan
¥
Mount gasket and put the oil pan there-
on.
¥
Place stiffeners and tighten bolts.
¥
Align the bolt holes with gasket holes to
prevent damage to the gasket and tight-
en to specified torque.
9.3.19. Intake and exhaust valves
¥
Identify the marks of ÒINÓ and ÒEXÓ
impressed on the valve head before
assembling the valve with the valve
head.
¥
With a valve stem seal fitting jig, assem-
ble the valve stem seal with the valve
guide.
¥
After installing valve springs and spring
retainer, press the retainer with a jig,
then install cotter pin.
¥
Tap the valve stem lightly with a rubber
hammer to check that the valve is
assembled correctly.
- 101 -
