40 PIPING AND INSTRUMENTATION SYSTEM
7/20, P65
KEY
Air
Oil
Air/oil
1 Air discharge
2 Sonic orifice (restricts flow)
3 Pressure gauge
4 Separator tank
5 Safety valve
6 Compressor
7 Engine
8 Oil cooler
9 Oil filter
