OPTIONS 43
7/20, P65
DESCRIPTION
This machine can be fitted with bund equipment to contain leakages
and spillages, which occur within the machine enclosure.
The bund will contain all fluids normally installed in the machine, plus
an additional 10%.
OPERATING INSTRUCTIONS
When fitted with bund, the machine must only be operated when level.
Drains for engine coolant, engine oil and compressor oil are located at
the front corner of the machine.
Bunded base must be drained daily.
The rear air intake is covered to prevent rainwater ingress. Ensure that
the cover is not prevented from moving.
DRAINING OF CONTAMINATED FLUIDS
Contaminated fluid must be removed by authorized personnel only.
Captured fluids can be drained from the bund by removing the plug or
uncoupling the flexible pipe secured at the left side of the machine. The
plug must be re-sealed after draining. The flexible pipe must be
re-secured after draining.
DRAINING OF MACHINE FLUIDS
During maintenance operations drain machine fluids using the drain
ports indicated
Remove fuel tank to drain.
DRAIN LOCATIONS
1. Engine coolant drain.
2. Engine oil drain.
3. Compressor oil drain.
4. Bunded base drain.
OPTION - BUNDED BASE
WARNING: Major leakages or spillages must be drained before
the machine is towed.
