Doran 360RV User Manual

TABLE OF CONTENTS
I. Introduction to the Doran 360RV-------------------------------------------------------------------------------------
Components-------------------------------------------------------------------------------------------------------------
Glossary of Terms-----------------------------------------------------------------------------------------------------
II. Setup and Installation
1. Monitor Installation-------------------------------------------------------------------------------------------------
2. Programming the System----------------------------------------------------------------------------------------
A. Programming the Sensor Location--------------------------------------------------------------------
B. Baseline Pressure Programming----------------------------------------------------------------------
C. Programming the Date & Time for Stored Alarm History---------------------------------------
D. Programming the Unit of Measure------------------------------------------------------------------
E. Delete Sensor Location--------------------------------------------------------------------------------
F. High Pressure Alarm Programming-----------------------------------------------------------------
III. Installing the Sensor on the Vehicle-----------------------------------------------------------------------------
IV. Alarm Modes-----------------------------------------------------------------------------------------------------------
1. First Stage Alarm for 12.5% Low-----------------------------------------------------------------------------
2. Second Stage Alarm for 25% Low---------------------------------------------------------------------------
3. High Pressure Alarm---------------------------------------------------------------------------------------------
4. Lost Sensor Alarm------------------------------------------------------------------------------------------------
V. Normal Mode Accessory Functions
1. Drop and Hook Feature-----------------------------------------------------------------------------------------
2. System Reset Function-----------------------------------------------------------------------------------------
3. Stored Alarm Information---------------------------------------------------------------------------------------
4. Backlight for Night Operations--------------------------------------------------------------------------------
VI. FAQs and Tips
1. Frequently Asked Questions----------------------------------------------------------------------------------
2. Tips-------------------------------------------------------------------------------------------------------------------
3. Limited Warranty--------------------------------------------------------------------------------------------------
4. Specifications------------------------------------------------------------------------------------------------------
VII. Optional Accessories------------------------------------------------------------------------------------------------29
1
2
2
3
4
5
7
8
11
12
13
14
16
17
17
18
18
19
20
20
21
22
25
26
28

Doran 360RV Specifications

Sensor Specifications

sensor transmit range	Approx. 130' (line of sight)
operating frequency	434.1 MHz FM
operating temperature range	-40 F to +257F
storage temperature range	-40F to +257F
sensor weight	Approx .85 oz
sensor dimensions	1.31 h x 1.16: diameter
sensor pressure range	10 to 188 psi +/- psi over operating pressure range
sensor low voltage shutdown	2.2 Volts

Monitor Specifications

monitor power requirements	12 VDC; Less than 100 mA when alarmed
monitor dimensions	5.7 w x 2.165 h x 1.1 d
monitor weight	5.4 oz
monitor power cord plug	Cigarette plug adapter or hard wire
monitor tire positions	1 to 36 positions
sensor alarm trigger settings	12.5% and 25% below the original tire inflation level
