7. ACCURACY: Designed to meet or exceed NIST Handbook 44
requirements
8. OPERATING TEMP.: + 14 degrees F to + 104 degrees F
9. POWER: 115 VAC, 50/60 Hz. 220 VAC optional.
10. MECHANICAL: a. 4100, 10" x 10" 18 1/2"H x 10"W x 14"D
b. 4100, 12" x 12" 18 1/2"H x 12"W x 17 "D
c. DSP4100 19"H x 16 1/2"W x 17"D
d. DSP4100/18S 24 1/2"H x 18"W x 24 1/2"D
e. DSP4100/1824 24 1/2"H x 24"W x 24 1/2"D
f. DSP4100/2424 24 1/2"H x 24"W x 30 1/2"D
VIII. OPTIONS FOR THE MODEL 4100
Type 1: Tower Extension: 6" or 12" higher. 6" extension is standard on Models
DSP4100/18S, DSP4100/1824, and DSP4100/2424.
Type 2: External Rotary Tolerance Switch: 16 position switch mounted on the
rear panel to provide external control of Over/Under tolerance.
Type 3: External Weight Display Selector: Pushbutton switch mounted next to
ZERO switch to change of weight display units externally.
Type 3A: Print request pushbutton: Option Type 6 required.
Type 4A: Remote Tower Platform: Used to separate tower and base. Tower is
mounted on a footed base and can stand alone.
Type 4B: Remote Tower-Wall Mount: Used to separate tower and base. Tower
has flanged bracket for wall mounting.
Type 5: Solid State Relay Output: Provides 1.0 amp/115VAC normally off SSR
output coincident with OVER, UNDER, and ACCEPT indicators.
Type 6: Serial Data Output: RS232 or 20 ma current loop
Type 7: Parallel BCD Data output
Type 11: Brine %-Pump Software: Allows for calculation of % added weight for
brine pumping operations.
Type 13: Audible Alarms: Audible beepers for OVER and UNDER.
DORAN MODEL 4100 OPERATING AND SERVICE MANUAL
MAN001R2
11
