Dorma TS 68 - Applications and Fixing; Door-leaf fixing, pull side; Frame fixing, push side; Parallel arm fixing, push side

DORMA TS 68 Applications and Fixing
3
TS 68 GB
Door-leaf fixing,
pull side
202C
A
B
30
64,5
E
D
45
28
19
50
Frame fixing,
push side
28
19
50
C
202
E
64,530
A
D
45
B
Parallel arm
fixing, push side
74
19
110
113
122
202
179
32
250
EN 2 EN 3 EN 4
A 170 170 250
B594343
C9696176
D 198.5 198.5 278.5
E8787167
EN 2 EN 3 EN 4
A 170 170 250
B594343
C9696176
D 198.5 198.5 278.5
E8787167
max. 15.5 (EN 2)
max. 19 (EN 3, 4)
max. 73.5 (EN 2)
max. 70 (EN 3, 4)
Colour xx
silver 01
brass 02
dark brown 03
white 11
Specification text
Rack-and-pinion door closer
with selectable closing
force, size EN 2, 3 and 4;
adjustable closing speed in
two independent ranges.
Non-handed.
Model
Y with standard arm
Y with hold-open
Colour
Y silver
Y brass
Y white (similar to RAL 9016)
Make DORMA TS 68
Door closer Standard arm Hold-open arm Parallel arm
TS 68 bracket
280066xx
Size EN 2/3/4
yY yY
#
664001xx 664002xx
Order-Number:
yY = Closer with arm,
= complete
# = Accessory
Standard equipment and
accessories
