METAL
QTY
(2)
WOOD
DOOR
DOOR
2
1
4
3
ACTION
7
Adjust sweep, latch, backcheck and delayed
action valves.
1 - SWEEP speed from
2 - LATCH speed from approx.
70° to 0°
7° to 0°.-(INCREASE ONLY)
DECREASE
INCREASE
SWEEP
RANGE
LATCH RANGE
CAUTION: DO NOT REMOVE VALVES.
BACKCHECK RANGE
4 - DELAY speed from max opening 180° to 70°
CAUTION: DO NOT CLOSE VALVE COMPLETELY.
DECREASE
INCREASE
BACKCHECK (INTENSITY)
3 - BACKCHECK cushion effect.
DELAY
RANGE
screw and tighten securely. Install track cover.
Attach arm to slide shoe.
Align hole in arm with slide shoe in track. Insert
QTY
(1)
8
5/64" HEX KEY
5
Assemble track and attach to door.
Attach track to door using track mounting screws.
Insert slide shoe and end blocks into track with spring block
near the hinge side of door frame.
HOLD OPEN ADJUSTMENT
ADDITIONAL INSTRUCTIONS (HOLD-OPEN UNITS):
hex key into the slide shoe bolt. Turn clockwise to increase
or counterclockwise to decrease holding force.
3. Open door until slide shoe engages with hold-open.
4. To release the door, pull until the slide shoe disengages.
2. Adjust the holding force by inserting a 5/64"
on, opposite direction off.
1. Adjust hold-open to on or off position. One direction
6
M5 HEX KEY
SPRING ON HINGE SIDE
08280611
2 of 3
08/09
INS NO.
PAGE
Rev.
