Dormakaba BTS80 - Sealing Compound (Optional); Covers; Install Cover

dormakaba BTS80, 80F Installation Instructions
08076346 12-2019BTS80 Closers
6
Sealing compound
Covers
. Sealing compound (optional)
Fig.
Sealing compound is recommended for exterior doors or areas
with excessive moisture. Make all final adjustments before adding
compound. Refer to instructions packed with compound for full
details.
4 Covers
. Install cover
Fig.
4.1.1 Trim cover plate as required to match
profile of pivot jamb.
4.1.2 Install cover plate with four screws
provided.
4.1.3 Press tab in place behind spindle.
4.1.4 If threshold is installed, do not anchor
threshold to closer body since closer is
adjustable within cement case.
QTY
(4)
Tab
