Confidant RFID ASM Mortise / Tubular Latch PK3692_T 02-19 19
Annex D- Install Bluetooth and Messenger
module
MESSENGER-A
MESSENGER-B
12
3
4
5
6
How to change orientation of Messenger antenna board. The lock is provided with orien-
tation of board for Messenger hub outside the room.
Orientation when Messenger
hub outside the room
Orientation when Messenger
hub inside the room
Position of Bluetooth
antenna board
