Confidant RFID ASM Mortise / Tubular Latch PK3692_T 02-19 3
Disclaimer
1- Tools
A
B
C D
E
F
A - Screw Driver Small Flat
B - Screw Driver Phillips #1 & #2
C - Screw Driver Torx T-20
D - Hexagonal Key 3 mm
E - 25mm / 24mm / 19mm / 12mm / 10mm Drill Bit
F - Needle Nose Pliers
CAUTION
Please read and follow all directions carefully. Wear safety glasses when making the holes.
IMPORTANT
Carefully inspect windows, doorframe, door, etc. to ensure that the recommended procedures will not
cause damage. Kaba Lodging Systems standard warranty does not cover damages caused by installation.
Respect applicable building codes regarding handle height.
Note: that the centerline of an ESM mortise does NOT pass through the screw holes on the strike.
